  • Diffusing LEDs Right

    Those are designed to be 3d printed. They are just some geometric shapes with a max dimension that I could still print on my printer. So the dimensions are not really connected to the light. The only thing that matters here is how far the diffuser is away from the LEDs. It was designed so the strip is double the distance away from the diffuser then the distance between each LED. That way the light from the LEDs intersect enough so that you don't see individual LEDs.It could have been smaller if I used double diffusion there like described in the other steps, but out of simplicity I designed these tools this way.

    View Instructable »
  • Both should work just fine, so it probably is more a question of aesthetics.There is special milky acrylic with the right amount of diffusion, usually called opal. These are made for such an application. Sandblasting diffusion can vary depending on grain size and time you blast it. So it can be more or less diffusion then the milky acrylic. But if you blast the inside the outer side will look more shiny like clear acrylic. On the other hand if you blast the outside you get extra diffusion because the clear surface reflects some light back and lets it bounce around inside. The outside will look rough.So all in all I guess it depends on what you want here.

    View Instructable »
  • Wouldn't help much. There is so much other stuff in it that would only be in the way, was complete communication using bluetooth to remote control the thing and more stuff. The parts I posted are essentially those that control the movement. Just put the outputs on the right pins of the controllers and call the function, should work then. If it doesn't there is most likely an issue with the wiring. Can put an LED on the step output and increase the delay time to check if signal is send to the driver.

    View Instructable »
  • Would have to dig into backups to find it, this was a long time ago. But I used A4988 stepper drivers. Just need to set them to the correct microstepping, then put the direction pin on high or low to set direction and pulse the step pin. Should be quite easy. There is also a good stepper library that is easy to use, check out the libraries on arduino homepage.

    Well found some of the code, but it is as I described above. Those stepper drivers have some pins to set microstep mode, one for direction and one to do the steps. Stepp code was this:int turnStep = A0;int turnDir = A1;int turnSpeed = 12;void turnByVal(int xw){ boolean posMove = xw >0; if (xw >0) { digitalWrite(turnDir, HIGH); } else { digitalWrite(turnDir, LOW); } for (int x=0;x<abs(xw);x++){ digitalWrite(turnStep, HIGH); //delay(1); digitalWrite(turnStep, LOW); delay(turnSpeed); }}Setting the microsteps this:int enableStepperPin = 2;int m1Pin = 3;int m2Pin = 4;int m3Pin = 5;void setStepSize(int stepSize) { switch(stepSize) { case 1: { // Full Step digitalWrite(m1Pin, LOW); digitalWrite(m2Pin, LOW); digitalWrite(m3Pin, LOW); …

    see more »

    Well found some of the code, but it is as I described above. Those stepper drivers have some pins to set microstep mode, one for direction and one to do the steps. Stepp code was this:int turnStep = A0;int turnDir = A1;int turnSpeed = 12;void turnByVal(int xw){ boolean posMove = xw >0; if (xw >0) { digitalWrite(turnDir, HIGH); } else { digitalWrite(turnDir, LOW); } for (int x=0;x<abs(xw);x++){ digitalWrite(turnStep, HIGH); //delay(1); digitalWrite(turnStep, LOW); delay(turnSpeed); }}Setting the microsteps this:int enableStepperPin = 2;int m1Pin = 3;int m2Pin = 4;int m3Pin = 5;void setStepSize(int stepSize) { switch(stepSize) { case 1: { // Full Step digitalWrite(m1Pin, LOW); digitalWrite(m2Pin, LOW); digitalWrite(m3Pin, LOW); break; } case 2: { // Half Step digitalWrite(m1Pin, HIGH); digitalWrite(m2Pin, LOW); digitalWrite(m3Pin, LOW); break; } case 3: { // 1/4 Step digitalWrite(m1Pin, LOW); digitalWrite(m2Pin, HIGH); digitalWrite(m3Pin, LOW); break; } case 4: { // 1/8 Step digitalWrite(m1Pin, HIGH); digitalWrite(m2Pin, HIGH); digitalWrite(m3Pin, LOW); break; } case 5: { // 1/16 Step digitalWrite(m1Pin, LOW); digitalWrite(m2Pin, LOW); digitalWrite(m3Pin, HIGH); break; } case 6: { // 1/32 Step digitalWrite(m1Pin, HIGH); digitalWrite(m2Pin, LOW); digitalWrite(m3Pin, HIGH); break; } }}Just put the relevant outputs on the pins of the driver and should work.

    View Instructable »
  • Real good instructable. Well explained and great details.Just wanted to add casein ist completely safe but "because it is made from milk" is not the best reasoning. You can extract pretty dangerous substances from food ingediences (poison/acid from almonds, drug/poison from nutmeg), so just because something is made from safe substances does not mean the result is too. (works the other way too)

    View Instructable »
  • Thanks, it has a lot of potential.

    View Instructable »
  • Continuous rotation servos are never precise. You can't tell them to go to a specific point/angle. You can just set the turn speed in one or the other direction. Once you mod a servo to have continuous rotation you disable the internal decoder and loose the ability to set a precise angle on them.The only servos that exist with more then 180° rotation are some servos used in model boats for the anchors. Those can have 2-5x360° rotation. But they are not really strong and not really precise and more, because you just spread the control range from 180° to a bigger angle so difference between each control step gets larger.

    View Instructable »
  • Servos usually only have 180° working area. Would work great, my first experiments were with those. But wanted to have more then the 180°. And once you modify them to have full 360° you loose the precision control and need to add a decoder or something like that to know where the arm currently is.

    View Instructable »
  • Was not able to get a full orb. What you see up there is the maximum I could get at the bottom. Partly because arm was longer then the height of the robot tower. Could have been better designed, but I wanted the longer arm. Speed was an issue, think that orb there took 5 minutes. Well it was programmed to be controllable using serial communication over bluetooth, that was one part that took some speed. Other was that I had not developed a proper code at that time. Would have been better to work with acceleration to get some more speed. Or add a gear box.

    Haha yes, hand made ones are sometimes only 180° depending on the type. Several years light painting experience. ;)I used one of those bearings that go under furniture. Around 30cm diameter with a hole in the middle that was perfect for the stepper. Added quite some stability.

    View Instructable »
  • It is normal wadding used in teddy bears and such stuff. Don't think it is fire safe but if you put an led strip in an aluminium enclosure they will never get warm enough to char the wadding.Usually getting those enclosures on ebay, many sell them here in different shapes and colors. Depends on where you live I guess.

    View Instructable »
  • Nice build. Check out my diffusion instructable if you want to get rid of the lines and get a continuous light bar ;)I bet some people in the lightpainter community would also love to read it. If you have facebook check out the "Light-Painting International" or "Light Painting World Alliance" group and share it there!
