Introduction: Bike Generator (mechanics)

Good morning.

This is about a bike generator (one more), that is an electrical power generator that takes movement from wheels and pedals of a bike (in fact, it converts the power of your legs into electrical power);

I already constructed the electrical part of the generator (you can see it in one of my previous Instructables), then I needed the mechanical part of the generator.

You can found several bike generators in Instructables' website (here are some examples: This, this, and this ).

I just was looking for a model that you can adapt on any bike with wheels of about 26", instead to have a "dedicated" and/or modified bike for this purpose.

Step 1: The Wheel's Support.

In order to support the bike leaving the rear wheel free to turn, I used a fork salvaged from another old bike (see draft); in this way you already have a shape that is suitable to fix the wheel without the need to dismount it from the bike used for the generator : just need to unscrew the two nuts of the rear wheel, put the same wheel on the fork (this fork will be installed upside-down, see picture) and re-tighten the nuts.

Now we just need a way to keep the fork vertical and stable...

Step 2: Boards Assembly Method.

The support is made of several wood board (I used scrap wood);

A way to keep together two boards perpendicularly, is to do 2 holes, like in the schema;

The first hole, the larger one, is about 20 to 30mm wide (around 1"); this empty space will receive the nut, and the larger diameter will give us enough space to insert a tool to tighten it. I usually keep the hole 1cm away (around 1/2") from the edge of the board, in order to leave enough wood for the bolt-and-nut to catch.

The second hole passes through the 2nd board, enters the first board in its thickness and pass through the 'larger' hole perpendicularly. I usually choose the diameter of this 2nd hole 1mm larger than the screw that I will use: in this case, 6mm screw and 7mm drill bit.

Step 3: The 3 Main Pieces.

For the main support, I use 3 boards (wood form scrapped furniture): 2 of them (lighter colour in the picture) were around 20cm (8") square, about 20mm thick; no need to be very precise, and no need to be really square.

the 3rd board was around 10 x 60cm, 18mm thick.

Step 4: The Cut-out Shape (detail)

This is the detail about board N°1;

the U-shaped cut-out has to be a little bit (let's say 1/10 inch) larger than the base board; in this way, during installation we could shift a little bit the board to compensate an eventual imprecision in the holes' position.

Step 5: The Perpendicular Holes (detail)

Here some details about the holes in the board N°2.

Maybe the picture isn't clear, but the two 7mm holes are parallel one to the other;

The distance between the two 7mm holes has to be the same distance between the screws.

Step 6: Assembly: Board N°1

- Put the two M6x65mm screws through the base board, inserting them from bottom: the heads of the screws will remain, at the end, hidden under the base board.

- put the board N°1 vertically on the base board, as in the picture (the U-shaped cut-out is downward); the screws have to get into the two 7mm holes: that's why is maybe useful to drill the hole a little bit larger than the screws, insertion will be easier even if the holes' position isn't very precise.

- fix screws and boards wit the 2 nuts, as in the picture. Tighten the nuts.

Step 7: Assembly: Board N°2

It works just as for the board N°1:

- put the two M6x65mm screws through the base board, inserting them from bottom.

- put the board N°1 vertically on the base board: the screws have to get into the two 7mm holes.

- fix screws and boards wit the 2 nuts; tighten the nuts.

Step 8: Improving the Fork's Fixing (details)

(... sorry for my English ...)

We can fix the upside-down fork to the vertical boards with some shaped metal bar; as the boards are perpendicular one to the other, the fork will be stable in all directions.

Step 9: Board N°3

I added another 6x60cm wood board, about 15mm thick, perpendicularly to the base board (see picture), in order to stabilize the support.

Please notice that I had to add two small pieces of wood under the board N°3 (one piece at both end, as in the picture), otherwise this board N°3 won't touch the ground and couldn't stabilize nothing at all.

Board N°4 is a shelf that will receive the generator: some details in next step.

Step 10: The Generator's Shelf

About the generator's shelf that you could perceive in previous step:

- this board ('N°4') is about 20x25 cm (8"x10"), about 18mm thick;

- the 'fixing holes' in the picture are about 6mm wide (once more, they are a little larger than the screws that will be used - I used four 5 x 40mm wood screws), and about 10cm spaced; of course number, position and type of screws are free, the important is that you can fix this shelf on the base board in a reliable way.

- the vertical bolt-and-nuts: they will receive the generator's shifting support (see next step); in the picture screws are M6x50 (roughly) screws. Please notice that around the nuts there are two 'bowls', dig with a 15mm drill tip, in order to keep nuts recessed UNDER the top surface of the wood board (as in the drawing).

Step 11: The Generator's Shifting Support

For this support, I used a 10x22cm (roughly) 18mm thick wood board;

At one side the generator was fixed (1st picture); at the opposite side I dig a 12cm long / 8mm wide slot (2nd picture);

Once the support board is installed as in 3rd picture, it could be shifted along some cm in order to adapt the generator's position to the bike's wheel; than you can easily fix it in the chosen position with 2 washers and 2 nuts.

Step 12: Generator's Wheel

For the generator wheel, a 68mm (roughly) round wood piece was cut with a bell saw;

Luckily, the central hole was just ideal for the generator's shaft; so, this wheel is kept on the shaft only by friction between metal and wood!

This wooden wheel will be placed in contact with the bike's wheel (see 3rd picture): they will turn together in opposite directions.

Step 13: Pedaling.

Now, all is ready;

Just pedal fast enough to get at least about 13Volt; in the picture, the voltmeter on the red box has a 40 V end-of scale, so in that moment we got about 20V generated.

The lamp was a 12V led bulb (indicating success!)

Step 14: Test in Real Conditions - Further Improvements

Recently, a second version of the bike generator was made: both a new mechanical support and a new electrical adapter; the only real difference was that the new adapter includes a charger for a Lead-acid 12V battery;

We used the generator in a local 'bike festival' (see picture): the adapter supplied a 5V led stripe (not very visible, in that sunny day...) connected on the USB outlet and a boom-box modified to be supplied at 12Vdc.

As the generator was intended for a pedagogical use, we didn't use any battery for the moment, in order to show that the power was coming ONLY from the bike (no pedaling, no music).
