Introduction: Vinyl Record Clock Art

About: I am a self taught average carpenter. I started doing carpentry for the first time in 2010. I have moved up to being a finish carpenter and installer. I am also self taught on Auto CAD and Adobe Illustrator…

This is a concept I saw online and wanted to make for my father's birthday that was coming up.

Supplies

Vinyl Record

Design Software (I use Adobe Illustrator)

Laser Engraver/Cutter

Drill

Clock Mechanism

Baterry (for clock)

Step 1: Buy the Records

First thing is to get the supplies so you know what you are working towards. I went to Ebay and bought 25 records (for about $1 each). They had a rating of "for craft" due to scratches or some other imperfection that did not let it play properly.

Step 2: FIND AND PREP ARTWORK

I went online and found a silhouette images for the records that I bought. As these were "craft" records, I was not certain exactly what albums I would receive. Thankfully the seller on Ebay was willing to work with me and put in some great albums that my parents are fans of.

Note: on the prepping, I was using a red and blue lines. This is for "vector cut" and "etching". Red is cutting and for the blue, I turned it off but instead used it to help place the album where I wanted in the laser bed.

It was important to make sure that the red and blue lines were exactly where I wanted them so no unnecessary cutting occurred. You can see on the Eagles and Fleetwood Mac test I did above, the entire top is cut off, but nothing needs to be cut off the bottom. So, I put a blue line on the bottom half that connects with the red line (where I want it to cut).

The Fleetwood Mac image is on the computer, where I can see the lines to be cut and then I copied and filled in with black so I can see a preview of what it will look like in the end.

On the Eagles photo, this is a real record and I used it for some testing to make sure that my laser would actually cut through the records with no issues.

So, one of the albums I got was an Aerosmith Album. I found the image I wanted and created the lines needed for cutting out.

Step 3: LASERING

This step was easy, as all was prepped, I first cut out a template so that I could get the exact placing in the laser bed. Once I lined it up in my laser cutter, I just pushed play.

I then cleaned off any burn marks and it was ready for the clock parts.

Step 4: FINISH UP WITH THE CLOCK PARTS

Next came time to put the clock mechanism together with the record.

First problem was that the shaft of the clock was a little bigger than the hole in the middle of the record. I used a drill bit to make this a little bigger to allow the clock to fit. I then assembled all the clock parts and put the battery in.

It turned out amazing! I love it. I sent it to my father for his birthday and he was very happy with it.
